CAME ZR24 - Activating the Radio Control

ACCES.
LINE
-A.C.T.+
-ENC+
1 2 3 4 5 6 7 8 9 10 11 12
05 06 07 08 09 V1 V2 V3
ZE7
OP./CL.
CONTROL
5A
C. BOARD
1,6A
CH1/OP.
CLOSE
BOARD
630mA
ï ï
V
W
U
E1
E3
10 11 12357C1 FA
TOP TAM
QUADRO COMANDO
ZR24
UV WE1
10
11
12 7C1
E3
L1 L2
Page
13
13 - Manual code:
319T07EN
319T07EN
ver.
3
3 05/2014 © CAME cancelli automatici S.p.A.
The data and information provided in this manual are subject to change at any time without prior notice.
⚠
DISCONNECT LINE VOLTAGE AND REMOVE THE BATTERIES, IF
PRESENT
Insert the AF card on the control board.
The control board only recognises the AF card when the operator is powered again.
AF card
For the AF43S / AF43SM radiofrequency cards
only, position the jumper as shown according to
the series of transmitters used.
Activating the radio control
