Clearing Paper Jams
3-18
3
Troubleshooting
4
Remove any jammed paper from the stack bypass inside the right cover of
the main unit.
5
Place your hand where the hand symbol ( ) is located on the right cover of
the main unit, and then gently close the right cover until it clicks into place
in the closed position.
If the optional Paper Deck-Q1 was moved away from the main unit, reconnect it to the main unit. For
more information, see e-Manual > Optional Equipment.
When closing the upper and lower right covers of the main unit, be careful not to get your
fingers caught, as this may result in personal injury.
