Canon EOS 40D - Page 17

17
Nomenclature
Tripod socket
Extension system
terminal
Battery compartment
cover (p.26)
Battery
compartment
cover release
lever (p.26)
<V> Focal plane mark
<9> Multi-controller (p.34)
Viewfinder eyepiece
Eyecup (p.97)
Dioptric adjustment knob (p.35)
Strap mount
(p.23)
Access lamp (p.29)
CF card slot
cover (p.28)
CF card slot (p.28)
CF card eject button (p.29)
LCD monitor
(p.36, 125)
<S/u>
AF point selection/
Enlarge button
(p.78/120,141)
<p>AF start button
(p.32,76,114)
<A/I> AE lock/
FE lock button/Index/
Reduce button
(p.95/102/119/120,141)
<M> Menu
button (p.36)
<l> Print/
Share button
(p.139,149)
<B> Info/Trimming
orientation button
(p.112,116,168/141)
<C> Jump
button (p.119)
<x> Playback
button (p.116)
<A> Picture Style selection
button (p.61)
<L> Erase
button (p.124)
<5> Quick Control Dial (p.34)
<0> Setting button (p.36)
Power/Quick Control Dial
switch (p.32)
