Page #257 background imageLoading...
Page #257 background image
E Roll Paper Margin for Safety
You can specify the length of a margin on the leading edge of paper to ensure that paper susceptible to curling is
held firmly against the Platen.
F Near End Margin
Specify the length of the Near End Margin (the leading edge margin) of the roll, as needed.
Setting Item Details
Printer Default The setting of the control panel of the printer is applied.
3 mm (0.12 in) The document is printed in the standard size.
* Select this when you do not have any problems in printing.
20 mm (0.8 in) Select this when rubbing against the printhead occurs such as when using paper that
tends to curl.
G Cut Speed
Select the speed of automatic cutting, as needed. You can adjust this setting if paper is not cut well when automatic
cutting is used.
Setting Item Details
Printer Default The setting of the control panel of the printer is applied.
High Speed When the Standard setting does not result in a clean cut surface, select this.
Standard Select this when you do not have any problems in automatic cutting.
Low Speed This helps prevent adhesive from sticking to the cutter and keeps the cutter sharp if you
select it when using adhesive paper.
H Automatic Cutting
Set whether to perform roll cutting automatically or print a cut line.
The following settings are available for automatic cutting.
Setting Item Details
Printer Default The setting of the control panel of the printer is applied.
None After printing completes, the roll is not cut per page, and the next page of data is printed
successively.
Print Cut Guideline After printing completes, a line is printed per page, and the next page of data is printed
successively.
J Mirror
Specify whether to print a mirror image, as needed. Select this option to print a version of the document or image
with the left and right sides inverted.
iPF770
Paper Detailed Settings Dialog Box
User's Guide
Mac OS Software Printer Driver
257
