Page #446 background imageLoading...
Page #446 background image
Initial Settings
Initial Settings
Configuring the IP Address on the Printer ....................................................................................................... 446
Configuring the IP Address Using imagePROGRAF Device Setup Utility .................................................... 457
Configuring the IP Address Using the Printer Control Panel ....................................................................... 446
Configuring the IP Address Using ARP and PING Commands ................................................................... 447
Configuring TCP/IPv6 Network Settings ......................................................................................................... 448
Configuring the Printer Driver Destination (Windows) ...................................................................................... 449
Configuring the Printer Driver Destination (Mac OS) ........................................................................................ 449
Configuring the Printer's TCP/IP Network Settings With RemoteUI ................................................................. 450
Configuring the IP Address on the Printer
Configuring the IP Address on the Printer
You must configure the printer's IP address before using the printer in a TCP/IP network.
The printer's IP address is configured automatically when you install the printer driver following the instructions in
the Setup Guide.
Configure the IP address by using imagePROGRAF Device Setup Utility, the printer Control Panel, or ARP or
PING commands, if the IP address is changed, or if you change the printer connection mode to a network connec-
tion. For details on configuring the IP address, refer to the following topics.
Configuring the IP Address Using imagePROGRAF Device Setup Utility P.457 (Windows)
Configuring the IP Address Using the Printer Control Panel P.446
Configuring the IP Address Using ARP and PING Commands P.447
Important
If you use a DHCP server for automatic assignment of the printer's IP address, printing may no longer be possi-
ble after the printer is turned off and on. This is because an IP address different from before has been assigned.
Thus, when using DHCP server functions, consult your network administrator and configure the settings in one of
the following ways.
Configure the setting for dynamic DNS updating
In the printer menu, either set DNS Dync update to On, or activate the setting Enable DNS Dynamic Update in
RemoteUI.
(See "Menu Settings.") P.416
(See "Configuring the Printer's TCP/IP Network Settings With RemoteUI.") P.450
Configure the setting for assignment of the same IP address each time the printer starts up
Note
We recommend configuring the printer's IP address even if you will use the printer in networks other than TCP/IP
networks. Configuring the printer's IP address enables you to use RemoteUI to configure the network settings and
manage the printer with a web browser.
For details on RemoteUI,
see "Using RemoteUI."
P.444
Configuring the IP Address Using the Printer Control Panel
Configuring the IP Address Using the Printer Control Panel
This topic describes how to configure the printer's IP address on the Control Panel.
1
On the Tab Selection screen of the Control Panel, press or to
select the Settings/Adj. tab ( ).
Note
If the Tab Selection screen is not displayed, press the Menu button.
Configuring the IP Address on the Printer
iPF770
User's Guide
Network Setting Initial Settings
446
