5
Enter an administrator name/password and click the Install
Software button.
6
Click the Close button.
The installation of Media Configuration Tool is com-
plete.
Note
•
When the installation is completed properly, the Media Configuration Tool folder is saved in the following
folder.
Applications > Canon Utilities > Media Configuration Tool
Important
• After the installation is finished, update the media information by referring to Updating Media Information
After Installation ➔P.375 .
Updating Media Information After Installation
Updating Media Information After Installation
If you are running the Media Configuration Tool for the first time after installing it, you need to configure the media
information in the printer control panel and printer driver.
Important
•
You do not need to perform this procedure if you installed the printer driver using the User Software CD-ROM.
• Do not attempt to print or turn the printer off while the program is communicating with the printer.
1 From the Applications menu, select Canon Utilities > imagePROGRAF Media Configuration Tool >
CNWIMCT.
2
The Select Printer dialog box is displayed. Select
the printer for which to configure the media informa-
tion, and then click the Next button.
Note
•
The printers for which the printer driver is installed are displayed. If the printer you want to configure is not
displayed, check whether the printer driver for the target model is correctly installed.
• In the following screens, you cannot change the printer where media type information is to be updated.
iPF770 Updating Media Information After Installation
User's Guide
Handling and Use of Paper Media Configuration Tool (Mac OS)
375

Canon imagePROGRAF iPF770 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Page description languages	GARO, HP-GL/2, HP-RTL
Certification	CE, TUV, Gost-R, WEEE, ErP, EAC, RoHS, WEEE
Product color	Black, Grey
Sound pressure level (printing)	46 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet interface type	Gigabit Ethernet
Media thickness	0.07 - 1.5 mm
Maximum print size	A0 (841 x 1189 mm)
Maximum roll length	18 m
Media width (sheets)	914.4 mm
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1, A2, A3
ISO B-series sizes (B0...B9)	B1, B2, B4
Borderless printing media sizes	A0, A1, A2, A3, B4
Minimum system requirements	Windows XP, Vista, 7, 8, 8.1, Server 2003/2003R2, Server 2008/2008R2, Server 2012/2012R2 Mac X 10.6.8 - 10.10+
Power consumption (standby)	0.5 W
Power consumption (typical)	140 W
Power consumption (PowerSave)	5 W
Storage temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Sustainability certificates	ENERGY STAR
Accuracy	0.2 %
Scan speed (black)	3 ips
Scan speed (color)	1 ips

Weight and Dimensions

Depth	1100 mm
Width	1304 mm
Height	1062 mm
