Canon imagePROGRAF iPF770 User Manual

Messages regarding printheads
Messages regarding printheads
Cannot adjust printhead. ................................................................................................................................ 567
Wrong printhead. ............................................................................................................................................ 567
Printhead error ............................................................................................................................................... 567
Cannot recognize print head. .......................................................................................................................... 567
Execute printhead cleaning. ............................................................................................................................568
Cannot adjust printhead.
Cannot adjust printhead.
Cause Corrective Action
The Printhead nozzles are
clogged.
Execute Head Posi. Adj. again, as follows.
1. Press the OK button to clear the error.
2. Print a test pattern to check the nozzles.
(See "Checking for Nozzle Clogging.") ➔ P.502
3. Clean the Printhead if the nozzles are clogged.
(See "Cleaning the Printhead.") ➔ P.503
4. Execute Head Posi. Adj. again.
(See "Automatic Adjustment to Straighten Lines and Colors.") ➔ P.480
The Printhead cannot be
aligned; highly transparent film
is loaded.
Press the OK button to clear the error.
We recommend using a type of paper that you often use, other than film, for Printhead adjustment.
(See "Automatic Adjustment to Straighten Lines and Colors.") ➔ P.480
The Printhead is installed
crooked.
Straighten the Printhead as follows, and then execute Head Posi. Adj. again.
1. Press the OK button to clear the error.
2. Use Head Inc. Adj. to adjust the angle of inclination of the Printhead.
(See "Adjusting Line Misalignment.") ➔ P.483
3. Execute Head Posi. Adj. again.
(See "Automatic Adjustment to Straighten Lines and Colors.") ➔ P.480
Wrong printhead.
Wrong printhead.
Cause Corrective Action
An incompatible Printhead has been installed. Open the Top Cover and replace the Printhead with a new one.
(See "Replacing the Printhead.") ➔ P.504
Printhead error
Printhead error
Cause Corrective Action
There is a problem with the Printhead. Open the Top Cover and replace the Printhead with a new one.
(See "Replacing the Printhead.") ➔ P.504
Cannot recognize print head.
Cannot recognize print head.
Cause Corrective Action
No Printhead is installed. Follow these steps to install the Printhead.
1.
Open the Top Cover.
2. Install the Printhead.
(See "Replacing the Printhead.") ➔ P.504
The Printhead cannot be recognized because it is not installed correctly. Follow these steps to reinstall the Printhead.
1. Open the Top Cover.
2. Reinstall the Printhead.
(See "Replacing the Printhead.") ➔ P.504
iPF770 Cannot adjust printhead.
User's Guide
Error Message Messages regarding printheads
567

Canon imagePROGRAF iPF770 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Page description languages	GARO, HP-GL/2, HP-RTL
Certification	CE, TUV, Gost-R, WEEE, ErP, EAC, RoHS, WEEE
Product color	Black, Grey
Sound pressure level (printing)	46 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet interface type	Gigabit Ethernet
Media thickness	0.07 - 1.5 mm
Maximum print size	A0 (841 x 1189 mm)
Maximum roll length	18 m
Media width (sheets)	914.4 mm
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1, A2, A3
ISO B-series sizes (B0...B9)	B1, B2, B4
Borderless printing media sizes	A0, A1, A2, A3, B4
Minimum system requirements	Windows XP, Vista, 7, 8, 8.1, Server 2003/2003R2, Server 2008/2008R2, Server 2012/2012R2 Mac X 10.6.8 - 10.10+
Power consumption (standby)	0.5 W
Power consumption (typical)	140 W
Power consumption (PowerSave)	5 W
Storage temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Sustainability certificates	ENERGY STAR
Accuracy	0.2 %
Scan speed (black)	3 ips
Scan speed (color)	1 ips

Weight and Dimensions

Depth	1100 mm
Width	1304 mm
Height	1062 mm
