Caution
•
Do not force the Roll Holder into the printer with the right and left ends reversed. This may damage the
printer and Roll Holder.
•
Do not release the flanges until the holder is loaded in the Roll Holder Slot.
•
Be careful not to pinch your fingers between the Roll Loading Slots (b) and the Roll Holder shaft (c) when
loading rolls.
6
Insert the edge of the roll in the Paper Feed Slot (a) and
advance the roll until you hear the feed tone.
Important
•
Be careful not to soil the printing surface of roll paper as you insert it in the slot. This may affect the
printing quality. We recommend wearing clean cloth gloves when handling rolls to protect the printing
surface.
•
If the paper is wrinkled or warped, straighten it out before loading it.
•
Load paper straight so it is not fed askew.
7
Once paper feeding starts, you will need to do the following, based on the
ManageRemainRoll setting and
the barcode printed on rolls. (See "Keeping Track of the Amount of Roll Paper Left.") ➔ P.331
ManageR-
emainRoll
Barcodes Printer Operation After the Paper is Fed
Off Printed A menu for selection of the type of paper is automatically shown on the Display Screen.
Press ▲ or ▼ to select the type of paper, and then press the OK button.
Not prin-
ted
On Printed The type and amount of paper left is automatically detected based on the barcode printed on the roll.
There is no need to specify the type and length of the paper.
Not prin-
ted
A menu for selection of the paper type and length is automatically shown on the Display Screen.
Press ▲ or ▼ to select the type and length of paper loaded, and then press the OK button.
Note
•
For details on types of paper to select, see the Paper Reference Guide. (See "Displaying the Paper Ref-
erence Guide.") ➔P.313
Loading Rolls in the Printer
iPF770
User's Guide
Handling and Use of Paper Handling rolls
324
To Next Page
