2
The Edit Media Types dialog box is displayed.
3
In the Media Type list, select the name of the media
to switch off or on for display.
Click the Show/Hide button.
The selected paper is alternately shown or hidden.
Note
You can select multiple paper.
The names of media switched for non-display appear grayed out in the Media Type list.
Each time you click the Show/Hide button, the display mode cycles from showing both the printer driver
and printer panel, to hiding both the printer driver and printer panel, and then to showing only the printer
panel.
4
In the Edit Media Types dialog box, click the Update
button.
5
The Confirm Update dialog box is displayed.
Configure Update Target and click the Execute but-
ton.
The printer control panel and printer driver media in-
formation is updated.
Switching Media Types Display Show/Hide
iPF770
User's Guide
Handling and Use of Paper Media Configuration Tool (Windows)
368
