Canon imagePROGRAF iPF770 User Manual

Setting Item Description, Instructions
System
Setup
Keep Paper Size
Choose Off to give priority to margin settings. The larger
value is used if the margin specified in the printer driver
does not match the margin in the printer menu.
TrimEdge Reload Specify whether to trim the leading edge of the currently
retracted roll when the roll is advanced. Cut the edge if
you are concerned about any marks left on the roll when
the roll is left in the retracted position.
Specify On to have rolls cut when printing begins after
Sleep mode or when the power is restored. Selecting Au-
tomatic will trim the edge when the roll has been in the
retracted position for two days or more.
Rep.P.head Print Choose On to have the printer automatically execute the
Advanced Adj. operations after you replace the Print-
head. (See "Automatic Adjustment to Straighten Lines and
Colors.") ➔P.480
Nozzle Check In Frequency, specify the timing for automatic checks of
nozzle clogging. Choose Standard to have the printer ad-
just the timing for checks based on the frequency of noz-
zle use. Choose 1 page to check once per page. Choose
10 pages to check once per 10 pages. Choose Off to not
execute check.
If On is selected in Warning, a warning may be displayed
on the Control Panel depending on the result of the nozzle
check.
Use USB When Off is selected, the device can no longer be ac-
cessed via USB.
Use Ethernet When Off is selected, the device can no longer be ac-
cessed via Ethernet.
Use RemoteUI Choosing Off prohibits access from RemoteUI. Settings
can only be configured from the control panel.
Reset PaprSetngs Restores settings that you have changed with Media Con-
figuration Tool to the default values.
Show Job Log Selecting Off prevents display of the log in Job Menu >
Job Log. Additionally, the log is not printed if you choose
Job Menu > Print Job Log. Note that because job logs
are not collected, the Status Monitor accounting functions
will not work correctly.
Prep.MovePrinter Select this option when transferring the printer to another
location.
Follow the instructions displayed to complete the required
procedure.
(See "Preparing to Transfer the Printer.") ➔ P.518
Not displayed during a warning message that the remain-
ing Maintenance Cartridge capacity is low.
Menu Settings iPF770
User's Guide
Control Panel Printer Menu
424

Canon imagePROGRAF iPF770 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Page description languages	GARO, HP-GL/2, HP-RTL
Certification	CE, TUV, Gost-R, WEEE, ErP, EAC, RoHS, WEEE
Product color	Black, Grey
Sound pressure level (printing)	46 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet interface type	Gigabit Ethernet
Media thickness	0.07 - 1.5 mm
Maximum print size	A0 (841 x 1189 mm)
Maximum roll length	18 m
Media width (sheets)	914.4 mm
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1, A2, A3
ISO B-series sizes (B0...B9)	B1, B2, B4
Borderless printing media sizes	A0, A1, A2, A3, B4
Minimum system requirements	Windows XP, Vista, 7, 8, 8.1, Server 2003/2003R2, Server 2008/2008R2, Server 2012/2012R2 Mac X 10.6.8 - 10.10+
Power consumption (standby)	0.5 W
Power consumption (typical)	140 W
Power consumption (PowerSave)	5 W
Storage temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Sustainability certificates	ENERGY STAR
Accuracy	0.2 %
Scan speed (black)	3 ips
Scan speed (color)	1 ips

Weight and Dimensions

Depth	1100 mm
Width	1304 mm
Height	1062 mm
