Canon imagePROGRAF iPF780 User Manual

• E Format Settings
Click to display the Format Settings dialog box, which enables you to complete format-related settings.
Note
• If you specify the same position for multiple items, the items are printed from left to right in this order: date,
user name, and page number.
• When you print multiple pages per sheet using Page Layout Printing or similar functions, these items will be
printed for each page.
Special Settings Dialog Box
Special Settings Dialog Box
If the printing results are not as you expected, you can change how printing is processed in the Special Settings
dialog box.
Note
• To display the Special Settings dialog box, on the Layout sheet, click Special Settings. (See "Layout
Sheet .") ➔P.164
• Click the processing method for Parameter within the Settings Summaries frame to display a list of the setting
details under the frame.
• A Spooling at Printer Driver
Sets whether or not print jobs are spooled in the printer driver and processed by PageComposer.
Printing results may be improved in some cases by setting this to No or No (EMF Spooling).
Note
• When set to No or No (EMF Spooling), functions such as Page Layout, Watermark, Reverse Order, Page
Options, FineZoom Settings, and Preview Switchingcan no longer be used.
• B FineZoom Settings
This function is used in large-format printing.
If it is set to Yes, problems in the printing may be improved.
If it is set to No, image distortions such as fine lines disappearing may be improved.
• C Preview Switching
When this setting is turned on, PageComposer starts when printing is performed with the Open Preview
When Print Job Starts check box selected in the Main sheet.
• D
Application Color Matching Priority
When this is on, you can give applications priority in color management.
Special Settings Dialog Box
iPF780
User's Guide
Windows Software Printer Driver
166

Canon imagePROGRAF iPF780 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.07 - 0.8 mm
Maximum print size	-
Media width (rolls)	254 - 914.4 mm
Media width (sheets)	203.2 - 914.4 mm
Maximum roll diameter	150 mm
Paper tray media types	Coated paper, Cut sheet, Plain paper, Roll
ISO A-series sizes (A0...A9)	A0, A1, A2, A3
ISO B-series sizes (B0...B9)	B1, B2, B4
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100/1000 Base-T/TX Mbit/s
Ethernet interface type	Gigabit Ethernet
Certification	RoHS
Product color	Black, Grey
Internal memory	256 MB
Sound pressure level (printing)	48 dB
Compliance industry standards	IEEE 802.3ab, IEEE 802.3u, IEEE 802.3
Power consumption (standby)	0.5 W
Power consumption (typical)	140 W
Storage temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	877 mm
Width	1304 mm
Height	1062 mm
