Feeding Roll Paper Manually
Feeding Roll Paper Manually
After a roll has been advanced, you can press the Feed button to feed or retract the roll with the and buttons.
1
Press the Feed button.
2
Press the or button to advance or retract the roll.
Press to retract the roll manually.
Press to advance the roll manually.
Note
If you hold down or for less than a second, the roll will move about 1 mm (0.04 in).
If you hold down or for more than a second, the roll will move until you release the button. Release the button
when the Display Screen indicates "End of paper feed. Cannot feed paper more.".
Keeping Track of the Amount of Roll Paper Left
Keeping Track of the Amount of Roll Paper Left
Setting ManageRemainRoll to On in the Paper Menu of the Control Panel will print a barcode with text on the roll
when the roll is removed that identifies the type of paper and amount left. When ManageRemainRoll is On and
you load rolls with printed barcodes, the type of paper and amount left are automatically detected after rolls are
loaded. The barcode will be cut off after it has been read.
Important
If the barcode on the roll is not detected, enter the type and length of paper on the Control Panel.
Follow these steps to set ManageRemainRoll to On as follows.
1
On the Tab Selection screen of the Control Panel, press or to
select the Paper tab ( ).
Note
If the Tab Selection screen is not displayed, press the Menu button.
2
Press the OK button.
The Paper Menu is displayed.
3
Press or to select ManageRemainRoll, and then press the OK button.
4
Press or to select On, and then press the OK button.
iPF780
Feeding Roll Paper Manually
User's Guide
Handling and Use of Paper Handling rolls
347
