Canon imagePROGRAF iPF780 User Manual

8
Pull the Release Lever forward.
Roll paper cannot be inserted into the Paper Feed Slot
Roll paper cannot be inserted into the Paper Feed Slot
Cause Corrective Action
The roll paper is warped. Straighten out curls and reload the roll.
Paper is jammed by the paper feed slot. Remove the jammed paper.
(See "Clearing Jammed Roll Paper.") ➔ P.527
(See "Clearing a Jammed Sheet.") ➔ P.530
The paper source selection is incorrect. Press the Load button and select the paper source.
Cannot load sheets
Cannot load sheets
Cause Corrective Action
The paper source selection is incorrect. Press the Load button and select the paper source.
Paper is not cut neatly
Paper is not cut neatly
Cause Corrective Action
The paper is bent or curled at the cut position. Straighten out any curling by the edges of the paper.
Paper rises by the ends of the cut position be-
fore it is cut.
Reload the paper correctly.
You are using paper that cannot be cut with the
Cutter Unit.
Specify Manual in Cutting Mode in the Control Panel menu and use scissors or
a cutting tool to cut the roll after printing.
(See "Specifying the Cutting Method for Rolls.") ➔ P.349
Cut Speed is not configured correctly in the
Control Panel menu.
Change the Cut Speed setting in the Control Panel menu.
(See "Menu Structure.") ➔P.408
During cutting, printed documents fall out at an
angle.
In the Control Panel menu, set Cutting Mode to Eject. Hold documents after
printing, as they are cut.
(See "Specifying the Cutting Method for Rolls.") ➔ P.349
Paper is not cut
Paper is not cut
Cause Corrective Action
In the printer driver, No or Print Cut Guideline is specified in
Automatic Cutting.
Specify Yes in Automatic Cutting in the printer driver.
(See "Page Setup Sheet (Windows).") ➔ P.161
(See "Paper Detailed Settings Dialog Box (Mac OS).") ➔ P.256
In the Control Panel menu, Cutting Mode is set to Eject or
Manual.
If the Cutting Mode is Eject, press the Cut button to cut the paper.
If the Cutting Mode is Manual, cut rolls with scissors or the like.
(See "Specifying the Cutting Method for Rolls.") ➔ P.349
Roll paper cannot be inserted into the Paper Feed Slot iPF780
User's Guide
Troubleshooting Problems Regarding Paper
534

Canon imagePROGRAF iPF780 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.07 - 0.8 mm
Maximum print size	-
Media width (rolls)	254 - 914.4 mm
Media width (sheets)	203.2 - 914.4 mm
Maximum roll diameter	150 mm
Paper tray media types	Coated paper, Cut sheet, Plain paper, Roll
ISO A-series sizes (A0...A9)	A0, A1, A2, A3
ISO B-series sizes (B0...B9)	B1, B2, B4
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100/1000 Base-T/TX Mbit/s
Ethernet interface type	Gigabit Ethernet
Certification	RoHS
Product color	Black, Grey
Internal memory	256 MB
Sound pressure level (printing)	48 dB
Compliance industry standards	IEEE 802.3ab, IEEE 802.3u, IEEE 802.3
Power consumption (standby)	0.5 W
Power consumption (typical)	140 W
Storage temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	877 mm
Width	1304 mm
Height	1062 mm
