Canon imagePROGRAF iPF780 User Manual

2
Place the pointer at a corner of the selection box
around the object to show the arrow handle, and drag
this handle to change the object size.
Resizing by specifying a scaling value
1 Select an object.
2 Open the Format Dialog Box ➔ P.302 .
3 Use Scaling to set the magnification for enlargement or reduction. You either enter numbers directly.
Note
• You can input between 25 and 400.
• You can change the numbers by clicking either ▲ button or ▼ button.
4 Click the OK button.
Moving an Object
Moving an Object
You can move the object position.
1 Select an object.
2
Place the pointer inside the selection box of the ob-
ject to show the crosshair handle, and drag it to move
the object.
Rotating an Object
Rotating an Object
You can rotate the object.
1 Select an object.
Moving an Object iPF780
User's Guide
Mac OS Software Free Layout
304

Canon imagePROGRAF iPF780 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.07 - 0.8 mm
Maximum print size	-
Media width (rolls)	254 - 914.4 mm
Media width (sheets)	203.2 - 914.4 mm
Maximum roll diameter	150 mm
Paper tray media types	Coated paper, Cut sheet, Plain paper, Roll
ISO A-series sizes (A0...A9)	A0, A1, A2, A3
ISO B-series sizes (B0...B9)	B1, B2, B4
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100/1000 Base-T/TX Mbit/s
Ethernet interface type	Gigabit Ethernet
Certification	RoHS
Product color	Black, Grey
Internal memory	256 MB
Sound pressure level (printing)	48 dB
Compliance industry standards	IEEE 802.3ab, IEEE 802.3u, IEEE 802.3
Power consumption (standby)	0.5 W
Power consumption (typical)	140 W
Storage temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	877 mm
Width	1304 mm
Height	1062 mm
