Canon imagePROGRAF iPF780 User Manual

Setting Item Description, Instructions
Admin.
Menu
Change Password The restriction states and main items are shown below.
For more specific information on restricted items, see
"Menu Structure." ➔P.408
• Viewing and configuration by administrators only
Change Password
Init.Admin.Pswd
Etc.
• Viewing and configuration by administrators, and
only viewing by other users
Date & Time
Time Zone
Use RemoteUI
Etc.
Init.Admin.Pswd Choose OK to restore the Admin. Menu password to the
default values.
Adj. Fine Feed (*2) (*3) Displayed when you have selected Feed Priority > Adj.
Priority > Automatic or Print Quality. Fine-tune the feed
amount manually.
Printer
Info (*2)
Paper Info Indicates the current paper size, type, and related printer
settings.
Ink Info Indicates ink levels and maintenance cartridge capacity.
Head Info Indicates information about the printhead.
System Info Indicates the firmware version, serial number, and inter-
face information.
Error Log Indicates the most recent error messages (up to five).
Use Situation A counter for maintenance purposes.
Displays printer usage related information.
*1: A rough estimate of how much ink was consumed per job is displayed. Actual ink consumption may be different. The aver-
age margin of error for estimates calculated according to Canon measurement conditions for ink costs is ±15%. Canon does
not guarantee the accuracy of these estimates. Estimates may vary depending on conditions of use. Calculation of these
estimates does not include ink consumed when cleaning printheads by forceful ejection of ink.
*2: Displayed as the menu during printing while printing is in progress.
*3: Not displayed in the regular menu.
Status Print
Status Print
You can print a Status Print report indicating the current status of the printer.
With Status Print, information is printed regarding the printer firmware version, various settings, and the status of
consumables.
Printing Status Print reports
1 Load paper.
If using cut sheets, load paper A4/Letter-sized, you will need three sheets.
2
On the Tab Selection screen of the Control Panel, press ◀ or ▶ to
select Settings/Adj. tab (
).
iPF780 Status Print
User's Guide
Control Panel Printer Menu
423

Canon imagePROGRAF iPF780 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.07 - 0.8 mm
Maximum print size	-
Media width (rolls)	254 - 914.4 mm
Media width (sheets)	203.2 - 914.4 mm
Maximum roll diameter	150 mm
Paper tray media types	Coated paper, Cut sheet, Plain paper, Roll
ISO A-series sizes (A0...A9)	A0, A1, A2, A3
ISO B-series sizes (B0...B9)	B1, B2, B4
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100/1000 Base-T/TX Mbit/s
Ethernet interface type	Gigabit Ethernet
Certification	RoHS
Product color	Black, Grey
Internal memory	256 MB
Sound pressure level (printing)	48 dB
Compliance industry standards	IEEE 802.3ab, IEEE 802.3u, IEEE 802.3
Power consumption (standby)	0.5 W
Power consumption (typical)	140 W
Storage temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	877 mm
Width	1304 mm
Height	1062 mm
