Canon imagePROGRAF iPF780 User Manual

10
Push the Printhead Fixer Lever toward the back of the
printer until it clicks.
11
Close the Top Cover.
Ink now fills the system. It takes about seven minutes to
complete.
Important
• While ink is being filled, definitely do not remove the Ink Tank or Maintenance Cartridge. Ink may leak
out.
Note
• After Printhead has been replaced and filled with ink, Head Posi. Adj. ( Auto(Advanced) ) is performed if
you have selected Rep.P.head Print > On in the Control Panel menu. (See "Menu Settings.") ➔ P.414
In this case, follow the instructions on the Display Screen for Printhead adjustment.
If Rep.P.head Print is Off, perform Head Posi. Adj. ( Auto(Advanced) ) yourself. (See "Automatic Ad-
justment to Straighten Lines and Colors.") ➔ P.476
iPF780 Replacing the Printhead
User's Guide
Maintenance and Consumables Printheads
507

Canon imagePROGRAF iPF780 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.07 - 0.8 mm
Maximum print size	-
Media width (rolls)	254 - 914.4 mm
Media width (sheets)	203.2 - 914.4 mm
Maximum roll diameter	150 mm
Paper tray media types	Coated paper, Cut sheet, Plain paper, Roll
ISO A-series sizes (A0...A9)	A0, A1, A2, A3
ISO B-series sizes (B0...B9)	B1, B2, B4
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100/1000 Base-T/TX Mbit/s
Ethernet interface type	Gigabit Ethernet
Certification	RoHS
Product color	Black, Grey
Internal memory	256 MB
Sound pressure level (printing)	48 dB
Compliance industry standards	IEEE 802.3ab, IEEE 802.3u, IEEE 802.3
Power consumption (standby)	0.5 W
Power consumption (typical)	140 W
Storage temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	877 mm
Width	1304 mm
Height	1062 mm
