Canon imageRUNNER ADVANCE C3530i III Service Manual

■ Speed Control
Of the fans installed in this machine, the Front Fan (FM01), the Motor Fan (FM03), the Power Supply Cooling Fan (FM02) and
the Controller Fan (FM04) are subject to speed control. Each controller switches voltages to switch the fan rotation speed.
Fan Drive Sequence
Controlled by DCON MCON
Fan Name Front Fan
( FM01 )
Power Supply Cool-
ing Fan
( FM02 )
Motor Fan
( FM03 )
Controller Fan
( FM04 )
Standby Stopped Stopped Stopped Stopped
At printing 1-sided Half speed Full speed Half speed Full speed
2-sided Full speed Full speed Half speed Full speed
Reader operation Stopped Half speed Stopped Full speed
Sleep Stopped Stopped Stopped Stopped
Others JAM / ERR Stopped Half speed Stopped Stopped
Detection of rise
temperature
Full speed Full speed Full speed Stopped
Heater Control
Name Role
Cassette Heater (host machine) Prevents paper in the Cassettes 1/2 from absorbing moisture
Cassette Heater (Cassette Pedestal) Prevents paper in the Cassettes 3/4 from absorbing moisture
Reader Heater Prevents condensation on the Scanner Unit and the Reading Glass
Inside Heater Prevents condensation inside the machine
Conditions when each heater is turned ON
The heaters work as shown below when the Dehumidification Switch on the rear of the host machine is turned ON.
State
Reader Heater Cassette Heater
Inside Heater
22 deg C or less *1
22 deg C or higher
*1
Power OFF ON ON ON OFF
During deep sleep ON ON ON OFF
Sleep Standby / Sleep 1 OFF ON ON OFF
At standby OFF ON ON OFF
During printing operation OFF ON ON OFF
*1: External temperature can be checked in COPIER > DISPLAY > ANALOG > TEMP.
Power-saving Function
■ Overview
There are "Standby" and "Sleep" as the power supply mode of this machine.
Further, "Sleep" is divided into the following 3 modes: "Sleep Standby", "Sleep 1", "Deep Sleep".
2. Technology
127

Canon imageRUNNER ADVANCE C3530i III Specifications

General

Print Resolution	1200 x 1200 dpi
Interface	USB 2.0, Ethernet, Wi-Fi
Output Paper Capacity	250 sheets
Duplex Printing	Yes
Copy Resolution	600 x 600 dpi
Multiple Copies	Up to 999 copies
Magnification	25% - 400% (1% Increments)
Scan Resolution	600 x 600 dpi
Fax	Optional
Fax Resolution	400 x 400 dpi
Power Consumption (Maximum)	1.5 kW
Type	Color Laser
Functions	Print, Copy, Scan, Send, Store
First Print Out Time	5.9 seconds or less
Processor Speed	1.75 GHz
Memory	3.0 GB RAM
Hard Disk Drive	320 GB
Supported Media Types	Plain, Heavy, Recycled, Color, Label, Envelope
Supported Media Sizes	A3, A4, A5, B4, B5, Legal, Letter, Executive
Supported Media Weights	52-220 gsm
Pull Scan	Yes
Send Resolution	200 x 200 dpi, 300 x 300 dpi, 400 x 400 dpi, 600 x 600 dpi
Display	10.1-inch TFT LCD WSVGA Color Touch Panel
Mobile Printing	Available
