E614-0611-00 Flash PCB error
Detection Description An error was detected in the license-related area. (File could not be written in the Flash PCB after
startup or I/O error after startup)
Remedy
[Related parts]
- Flash PCB
- Main Controller PCB (UN05)
[Remedy] Perform the following in the order while checking whether the error is cleared.
1. Obtain the necessary backup data by referring to the backup data list.
[Reference] For backup and restoration, refer to "Adjustment> Main Controller System" and
"Appendix> Backup Data List" in the Service Manual.
2. After replacing the Flash PCB, reinstall the system software using SST or a USB flash drive.
3. Replace the Main Controller PCB.
[Reference] Before replacing the Main Controller PCB, back up the service mode data (approx. 2
min) and restore the backup data after the replacement so the data may be able to be protected.
- Backup: COPIER (LEVEL2)> FUNCTION> SYSTEM> RSRAMBUP
- Restoration: COPIER (LEVEL2)> FUNCTION> SYSTEM> RSRAMRES
E614-0701-00 Flash PCB error
Detection Description An error was detected in system setting value (service mode, etc.) storage area. (Initialization failed
at startup or I/O error at startup)
When this error occurs, the system has not been started normally. Therefore, it may not be
recorded in the error log.
Remedy
[Related parts]
- Flash PCB
- Main Controller PCB (UN05)
[Remedy] Perform the following in the order while checking whether the error is cleared. When
prioritizing clearing of the error, skip Remedies 2 and 3.
Although the error is cleared by "HD-CHECK", it may occur again. Thus, perform Remedies 1 to
4.
1. Check the related harness/cable and connector.
2. Select COPIER> FUNCTION> SYSTEM> CHK-TYPE> "8", and execute "HD-CHECK". Then,
turn OFF and then ON the main power.
3. Obtain the necessary backup data by referring to the backup data list.
[Reference] For backup and restoration, refer to "Adjustment> Main Controller System" and
"Appendix> Backup Data List" in the Service Manual.
4. Select COPIER> FUNCTION> SYSTEM> CHK-TYPE> "8", and execute "HD-CLEAR". Then,
turn OFF and then ON the main power.
[Reference] Only the data in the corresponding partitions is deleted.
5. Select COPIER> FUNCTION> SYSTEM> CHK-TYPE> "0", and execute "HD-CLEAR". Then,
turn OFF and then ON the main power.
[Reference] All the partitions that can be deleted are deleted.
6. After replacing the Flash PCB, reinstall the system software using SST or a USB flash drive.
7. Check/replace the related parts.
[Reference] Before replacing the Main Controller PCB, back up the service mode data (approx. 2
min) and restore the backup data after the replacement so the data may be able to be protected.
- Backup: COPIER (LEVEL2)> FUNCTION> SYSTEM> RSRAMBUP
- Restoration: COPIER (LEVEL2)> FUNCTION> SYSTEM> RSRAMRES
7. Error/Jam/Alarm
441
