E613-0512-00 Faulty/insufficient image memory
Detection Description No necessary memory at Main Controller PCB
Remedy
[Related parts] Main Controller PCB (UN05)
[Remedy] Check/replace the Main Controller PCB.
[Reference] Before replacing the Main Controller PCB, back up the service mode data (approx. 2
min) and restore the backup data after the replacement so the data may be able to be protected.
- Backup: COPIER (LEVEL2)> FUNCTION> SYSTEM> RSRAMBUP
- Restoration: COPIER (LEVEL2)> FUNCTION> SYSTEM> RSRAMRES
E613-1024-00 Faulty/insufficient image memory
Detection Description No necessary memory at Main Controller PCB
Remedy
[Related parts] Main Controller PCB (UN05)
[Remedy] Check/replace the Main Controller PCB.
[Reference] Before replacing the Main Controller PCB, back up the service mode data (approx. 2
min) and restore the backup data after the replacement so the data may be able to be protected.
- Backup: COPIER (LEVEL2)> FUNCTION> SYSTEM> RSRAMBUP
- Restoration: COPIER (LEVEL2)> FUNCTION> SYSTEM> RSRAMRES
E613-1536-00 Faulty/insufficient image memory
Detection Description No necessary memory at Main Controller PCB
Remedy
[Related parts] Main Controller PCB (UN05)
[Remedy] Check/replace the Main Controller PCB.
[Reference] Before replacing the Main Controller PCB, back up the service mode data (approx. 2
min) and restore the backup data after the replacement so the data may be able to be protected.
- Backup: COPIER (LEVEL2)> FUNCTION> SYSTEM> RSRAMBUP
- Restoration: COPIER (LEVEL2)> FUNCTION> SYSTEM> RSRAMRES
E613-2048-00 Memory error
Detection Description Memory of the Main Controller PCB is faulty.
Remedy
[Related parts] Main Controller PCB (UN05)
[Remedy] Check/replace the Main Controller PCB.
[Reference] Before replacing the Main Controller PCB, back up the service mode data (approx. 2
min) and restore the backup data after the replacement so the data may be able to be protected.
- Backup: COPIER (LEVEL2)> FUNCTION> SYSTEM> RSRAMBUP
- Restoration: COPIER (LEVEL2)> FUNCTION> SYSTEM> RSRAMRES
E614-0001-00 Flash PCB error
Detection Description The Flash PCB could not be recognized, or the Flash PCB was not formatted.
Remedy
[Related parts]
- Flash PCB
- Main Controller PCB (UN05)
[Remedy] Perform the following in the order while checking whether the error is cleared.
Reinstall the necessary application software once the error is cleared.
1. After turning OFF the main power, remove and then install the Flash PCB to check that it is
installed properly.
2. After replacing the Flash PCB, reinstall the system software using SST or a USB flash drive.
3. Replace the Main Controller PCB.
[Reference] For backup and restoration, refer to "Adjustment> Main Controller System" and
"Appendix> Backup Data List" in the Service Manual.
Before replacing the Main Controller PCB, back up the service mode data (approx. 2 min) and
restore the backup data after the replacement so the data may be able to be protected.
- Backup: COPIER (LEVEL2)> FUNCTION> SYSTEM> RSRAMBUP
- Restoration: COPIER (LEVEL2)> FUNCTION> SYSTEM> RSRAMRES
