Canon imageRUNNER ADVANCE C3530i III Service Manual

E003-0006-05 Fixing Sub Thermistor (Rear) low temperature detection error
Detection Description The Fixing Sub Thermistor (Rear) detected a temperature of 80 deg C or lower for 1 sec or longer
from start of PI control until completion of the last rotation (the Fixing Heater was turned OFF).
Remedy
[Related parts]
- Harness between the DC Controller PCB and the Fixing Unit
- Harness between the DC Controller PCB (J115) and the AC Driver PCB (J505)
- Harness between the AC Driver PCB and the Fixing Unit
- Fixing Unit
- Power Supply Unit
- DC Controller PCB
[Remedy] Check/replace the related harness/cable, connector and parts.
After performing the remedy work, go through the following to clear the error: COPIER>
FUNCTION> CLEAR> ERR.
[Reference] Before replacing the DC Controller PCB, back up the service mode data and restore
the backup data after the replacement so the data may be able to be protected.
- Backup: COPIER (LEVEL2)> FUNCTION> SYSTEM> DSRAMBUP
- Restoration: COPIER (LEVEL2)> FUNCTION> SYSTEM> DSRAMRES
E004-0001-05 Fixing Relay welding detection error
Detection Description Zero cross interruption was detected although the Fixing Relay was not turned ON.
Remedy
[Related parts]
- Harness between the DC Controller PCB (J115) and the AC Driver PCB (J505)
- Power Supply Unit
- DC Controller PCB
[Remedy] Check/replace the related harness/cable, connector and parts.
[Reference] Before replacing the DC Controller PCB, back up the service mode data and restore
the backup data after the replacement so the data may be able to be protected.
- Backup: COPIER (LEVEL2)> FUNCTION> SYSTEM> DSRAMBUP
- Restoration: COPIER (LEVEL2)> FUNCTION> SYSTEM> DSRAMRES
E004-0002-05 Current detection circuit error
Detection Description Current outside the specified range flowed to the Fixing Heater when the heater was turned ON.
Or, failure of fixing current detection circuit was detected.
Remedy
[Related parts]
- Harness between the AC Driver PCB (J302) and the Fixing Drawer (J1001)
- Harness between the DC Controller PCB (J115) and the AC Driver PCB (J322)
- Fixing Unit
- Power Supply Unit
- DC Controller PCB
[Remedy] Check/replace the related harness/cable, connector and parts.
[Reference] Before replacing the DC Controller PCB, back up the service mode data and restore
the backup data after the replacement so the data may be able to be protected.
- Backup: COPIER (LEVEL2)> FUNCTION> SYSTEM> DSRAMBUP
- Restoration: COPIER (LEVEL2)> FUNCTION> SYSTEM> DSRAMRES
7. Error/Jam/Alarm
332

Canon imageRUNNER ADVANCE C3530i III Specifications

General

Print Resolution	1200 x 1200 dpi
Interface	USB 2.0, Ethernet, Wi-Fi
Output Paper Capacity	250 sheets
Duplex Printing	Yes
Copy Resolution	600 x 600 dpi
Multiple Copies	Up to 999 copies
Magnification	25% - 400% (1% Increments)
Scan Resolution	600 x 600 dpi
Fax	Optional
Fax Resolution	400 x 400 dpi
Power Consumption (Maximum)	1.5 kW
Type	Color Laser
Functions	Print, Copy, Scan, Send, Store
First Print Out Time	5.9 seconds or less
Processor Speed	1.75 GHz
Memory	3.0 GB RAM
Hard Disk Drive	320 GB
Supported Media Types	Plain, Heavy, Recycled, Color, Label, Envelope
Supported Media Sizes	A3, A4, A5, B4, B5, Legal, Letter, Executive
Supported Media Weights	52-220 gsm
Pull Scan	Yes
Send Resolution	200 x 200 dpi, 300 x 300 dpi, 400 x 400 dpi, 600 x 600 dpi
Display	10.1-inch TFT LCD WSVGA Color Touch Panel
Mobile Printing	Available
