Canon imageRUNNER ADVANCE C3530i III Service Manual

E021-0001-05 Developing Motor error
Detection Description It did not become the specified speed although 0.8 sec have passed from the startup of the
Developing Motor.
Remedy
[Related parts]
- Main Drive Unit
- Harness between the Developing Motor and the DC Controller PCB
- Power Supply Unit
- Developing Motor (M10)
- DC Controller PCB
[Remedy] Perform the following in the order while checking whether the error is cleared.
1. Check whether the gears of the Main Drive Unit can be rotated by hand.
a. If they cannot be rotated, replace the Main Drive Unit.
b. If they can be rotated, check the harness between the Developing Motor and the DC Controller
PCB.
2. Measure the both ends of the fuse in the Low Voltage Power Supply Unit using a tester.
a. If the measurement value is less than 1 ohm (conduction state),
a-1. Replace the Bk Drum_ITB Motor.
a-2. Replace the DC Controller PCB.
b. If the measurement value is 1 ohm or higher (non-conduction state), replace the DC Controller
PCB.
[Reference] Before replacing the DC Controller PCB, back up the service mode data and restore
the backup data after the replacement so the data may be able to be protected.
- Backup: COPIER (LEVEL2)> FUNCTION> SYSTEM> DSRAMBUP
- Restoration: COPIER (LEVEL2)> FUNCTION> SYSTEM> DSRAMRES
E021-0002-05 Developing Motor error
Detection Description The specified speed could not be maintained although it became the specified speed at least once
from the startup of the Developing Motor.
Remedy
[Related parts]
- Main Drive Unit
- Harness between the Developing Motor (M10) and the DC Controller PCB
- Power Supply Unit
- Developing Motor (M10)
- DC Controller PCB
[Remedy] Perform the following in the order while checking whether the error is cleared.
1. Check whether the gears of the Main Drive Unit can be rotated by hand.
a. If they cannot be rotated, replace the Main Drive Unit.
b. If they can be rotated, check the harness between the Developing Motor and the DC Controller
PCB.
2. Measure the both ends of the fuse in the Low Voltage Power Supply Unit using a tester.
a. If the measurement value is less than 1 ohm (conduction state),
a-1. Replace the Bk Drum_ITB Motor.
a-2. Replace the DC Controller PCB.
b. If the measurement value is 1 ohm or higher (non-conduction state), replace the DC Controller
PCB.
[Reference] Before replacing the DC Controller PCB, back up the service mode data and restore
the backup data after the replacement so the data may be able to be protected.
- Backup: COPIER (LEVEL2)> FUNCTION> SYSTEM> DSRAMBUP
- Restoration: COPIER (LEVEL2)> FUNCTION> SYSTEM> DSRAMRES
7. Error/Jam/Alarm
351

Canon imageRUNNER ADVANCE C3530i III Specifications

General

Print Resolution	1200 x 1200 dpi
Interface	USB 2.0, Ethernet, Wi-Fi
Output Paper Capacity	250 sheets
Duplex Printing	Yes
Copy Resolution	600 x 600 dpi
Multiple Copies	Up to 999 copies
Magnification	25% - 400% (1% Increments)
Scan Resolution	600 x 600 dpi
Fax	Optional
Fax Resolution	400 x 400 dpi
Power Consumption (Maximum)	1.5 kW
Type	Color Laser
Functions	Print, Copy, Scan, Send, Store
First Print Out Time	5.9 seconds or less
Processor Speed	1.75 GHz
Memory	3.0 GB RAM
Hard Disk Drive	320 GB
Supported Media Types	Plain, Heavy, Recycled, Color, Label, Envelope
Supported Media Sizes	A3, A4, A5, B4, B5, Legal, Letter, Executive
Supported Media Weights	52-220 gsm
Pull Scan	Yes
Send Resolution	200 x 200 dpi, 300 x 300 dpi, 400 x 400 dpi, 600 x 600 dpi
Display	10.1-inch TFT LCD WSVGA Color Touch Panel
Mobile Printing	Available
