Canon imageRUNNER ADVANCE C3530i III Service Manual

E202-0002-04 Reader Scanner Unit HP error
Detection Description The Reader Scanner Unit could not detect the home position when completing scanning operation.
Remedy
[Related parts]
- Harness between the Main Controller PCB (UN05/J7005) and the Scanner Unit HP Sensor (PS_
A1/J5002)
- Harness between the Main Controller PCB (UN05/J7006) and the Scanner Motor (STM1/J5015)
- Scanner Unit HP Sensor (PS_A1)
- Scanner Motor (STM1)
- Main Controller PCB (UN05)
[Remedy] Check/replace the related harness/cable, connector and parts.
[Reference] Before replacing the Main Controller PCB, back up the service mode data (approx. 2
min) and restore the backup data after the replacement so the data may be able to be protected.
- Backup: COPIER (LEVEL2)> FUNCTION> SYSTEM> RSRAMBUP
- Restoration: COPIER (LEVEL2)> FUNCTION> SYSTEM> RSRAMRES
E202-0003-04 Reader Scanner Unit HP error
Detection Description An error in the Reader Scanner Unit position was detected when reading of a job was started.
Remedy
[Related parts]
- Harness between the Main Controller PCB (UN05/J7005) and the Scanner Unit HP Sensor (PS_
A1/J5002)
- Harness between the Main Controller PCB (UN05/J7006) and the Scanner Motor (STM1/J5015)
- Scanner Unit HP Sensor (PS_A1)
- Scanner Motor (STM1)
- Main Controller PCB (UN05)
[Remedy] Check/replace the related harness/cable, connector and parts.
[Reference] Before replacing the Main Controller PCB, back up the service mode data (approx. 2
min) and restore the backup data after the replacement so the data may be able to be protected.
- Backup: COPIER (LEVEL2)> FUNCTION> SYSTEM> RSRAMBUP
- Restoration: COPIER (LEVEL2)> FUNCTION> SYSTEM> RSRAMRES
E202-0004-04 Reader Scanner Unit HP error
Detection Description Home position error of the Reader Scanner Unit was detected when reading of a job was
completed.
Remedy
[Related parts]
- Harness between the Main Controller PCB (UN05/J7005) and the Scanner Unit HP Sensor (PS_
A1/J5002)
- Harness between the Main Controller PCB (UN05/J7006) and the Scanner Motor (STM1/J5015)
- Scanner Unit HP Sensor (PS_A1)
- Scanner Motor (STM1)
- Main Controller PCB (UN05)
[Remedy] Check/replace the related harness/cable, connector and parts.
[Reference] Before replacing the Main Controller PCB, back up the service mode data (approx. 2
min) and restore the backup data after the replacement so the data may be able to be protected.
- Backup: COPIER (LEVEL2)> FUNCTION> SYSTEM> RSRAMBUP
- Restoration: COPIER (LEVEL2)> FUNCTION> SYSTEM> RSRAMRES
E202-0010-04 Reader Scanner Unit HP error
Detection Description An error in the Reader Scanner Unit position was detected when reading of a job was started.
Remedy
[Related parts]
- Harness between the Main Controller PCB (UN05/J7005) and the Scanner Unit HP Sensor (PS_
A1/J5002)
- Harness between the Main Controller PCB (UN05/J7006) and the Scanner Motor (STM1/J5015)
- Scanner Unit HP Sensor (PS_A1)
- Scanner Motor (STM1)
- Main Controller PCB (UN05)
[Remedy] Check/replace the related harness/cable, connector and parts.
[Reference] Before replacing the Main Controller PCB, back up the service mode data (approx. 2
min) and restore the backup data after the replacement so the data may be able to be protected.
- Backup: COPIER (LEVEL2)> FUNCTION> SYSTEM> RSRAMBUP
- Restoration: COPIER (LEVEL2)> FUNCTION> SYSTEM> RSRAMRES
7. Error/Jam/Alarm
375

Canon imageRUNNER ADVANCE C3530i III Specifications

General

Print Resolution	1200 x 1200 dpi
Interface	USB 2.0, Ethernet, Wi-Fi
Output Paper Capacity	250 sheets
Duplex Printing	Yes
Copy Resolution	600 x 600 dpi
Multiple Copies	Up to 999 copies
Magnification	25% - 400% (1% Increments)
Scan Resolution	600 x 600 dpi
Fax	Optional
Fax Resolution	400 x 400 dpi
Power Consumption (Maximum)	1.5 kW
Type	Color Laser
Functions	Print, Copy, Scan, Send, Store
First Print Out Time	5.9 seconds or less
Processor Speed	1.75 GHz
Memory	3.0 GB RAM
Hard Disk Drive	320 GB
Supported Media Types	Plain, Heavy, Recycled, Color, Label, Envelope
Supported Media Sizes	A3, A4, A5, B4, B5, Legal, Letter, Executive
Supported Media Weights	52-220 gsm
Pull Scan	Yes
Send Resolution	200 x 200 dpi, 300 x 300 dpi, 400 x 400 dpi, 600 x 600 dpi
Display	10.1-inch TFT LCD WSVGA Color Touch Panel
Mobile Printing	Available
