Canon imageRUNNER ADVANCE C3530i III Service Manual

E199-0101-05 Error in high voltage sequence (Y)
Detection Description Error for collecting log.
Remedy
[Remedy] Collect debug log and contact to the sales company.
[Reference] By setting "COPIER (LEVEL2)> OPTION> FNC-SW> SELF-CHK" to "1", it is handled
as an error.
E199-0102-05 Error in high voltage sequence (M)
Detection Description Error for collecting log.
Remedy
[Remedy] Collect debug log and contact to the sales company.
[Reference] By setting "COPIER (LEVEL2)> OPTION> FNC-SW> SELF-CHK" to "1", it is handled
as an error.
E199-0103-05 Error in high voltage sequence (C)
Detection Description Error for collecting log.
Remedy
[Remedy] Collect debug log and contact to the sales company.
[Reference] By setting "COPIER (LEVEL2)> OPTION> FNC-SW> SELF-CHK" to "1", it is handled
as an error.
E199-0201-05 Error in high voltage sequence (Y)
Detection Description Error for collecting log.
Remedy
[Remedy] Collect debug log and contact to the sales company.
[Reference] By setting "COPIER (LEVEL2)> OPTION> FNC-SW> SELF-CHK" to "1", it is handled
as an error.
E199-0202-05 Error in high voltage sequence (M)
Detection Description Error for collecting log.
Remedy
[Remedy] Collect debug log and contact to the sales company.
[Reference] By setting "COPIER (LEVEL2)> OPTION> FNC-SW> SELF-CHK" to "1", it is handled
as an error.
E199-0203-05 Error in high voltage sequence (C)
Detection Description Error for collecting log.
Remedy
[Remedy] Collect debug log and contact to the sales company.
[Reference] By setting "COPIER (LEVEL2)> OPTION> FNC-SW> SELF-CHK" to "1", it is handled
as an error.
E199-0204-05 Error in high voltage sequence (K)
Detection Description Error for collecting log.
Remedy
[Remedy] Collect debug log and contact to the sales company.
[Reference] By setting "COPIER (LEVEL2)> OPTION> FNC-SW> SELF-CHK" to "1", it is handled
as an error.
E202-0001-04 Reader Scanner Unit HP error
Detection Description The Reader Scanner Unit could not detect the home position when starting scanning operation.
Remedy
[Related parts]
- Harness between the Main Controller PCB (UN05/J7005) and the Scanner Unit HP Sensor (PS_
A1/J5002)
- Harness between the Main Controller PCB (UN05/J7006) and the Scanner Motor (STM1/J5015)
- Scanner Unit HP Sensor (PS_A1)
- Scanner Motor (STM1)
- Main Controller PCB (UN05)
[Remedy] Check/replace the related harness/cable, connector and parts.
[Reference] Before replacing the Main Controller PCB, back up the service mode data (approx. 2
min) and restore the backup data after the replacement so the data may be able to be protected.
- Backup: COPIER (LEVEL2)> FUNCTION> SYSTEM> RSRAMBUP
- Restoration: COPIER (LEVEL2)> FUNCTION> SYSTEM> RSRAMRES
7. Error/Jam/Alarm
374

Canon imageRUNNER ADVANCE C3530i III Specifications

General

Print Resolution	1200 x 1200 dpi
Interface	USB 2.0, Ethernet, Wi-Fi
Output Paper Capacity	250 sheets
Duplex Printing	Yes
Copy Resolution	600 x 600 dpi
Multiple Copies	Up to 999 copies
Magnification	25% - 400% (1% Increments)
Scan Resolution	600 x 600 dpi
Fax	Optional
Fax Resolution	400 x 400 dpi
Power Consumption (Maximum)	1.5 kW
Type	Color Laser
Functions	Print, Copy, Scan, Send, Store
First Print Out Time	5.9 seconds or less
Processor Speed	1.75 GHz
Memory	3.0 GB RAM
Hard Disk Drive	320 GB
Supported Media Types	Plain, Heavy, Recycled, Color, Label, Envelope
Supported Media Sizes	A3, A4, A5, B4, B5, Legal, Letter, Executive
Supported Media Weights	52-220 gsm
Pull Scan	Yes
Send Resolution	200 x 200 dpi, 300 x 300 dpi, 400 x 400 dpi, 600 x 600 dpi
Display	10.1-inch TFT LCD WSVGA Color Touch Panel
Mobile Printing	Available
