Chapter 1
24
1.5 Installing the Heater
PCB
1.5.1 Unpacking and
Checking the Contents
0011-3362
iR2016J / iR2016 / iR2020 / / iR2016i / iR2020i
1) Prepare the following parts.
F-1-56
1.5.2 Preparing the Host
Machine
0011-3363
iR2016J / iR2016 / iR2020 / / iR2016i / iR2020i
Before installing, make sure the host machine is
turned off. If it is turned on, go through the following:
1. Turn off the main power switch.
2. Disconnect the power cable (from the power out-
let).
3. Disconnect the power cable.
F-1-57
1) Open the front cover [1].
F-1-58
2) Remove the four screws [1], and then detach the
rear cover [2].
3) Remove the five screws [3]. Remove the two hooks
[4], and then detach the lower-right cover [5].
4) Remove the screw [6], and then detach the upper-
right cover [7].
[1] Heater PCB unit 1 pc.
[2] Heater switch harness 1 pc.
[3] Cassette heater harness 1 pc.
[4] Heater PCB harness 1 pc.
[5] Clamp 4 pcs.
[6] Edge saddle (small) 2 pcs.
[7] Edge saddle (large) 1 pc.
[8] P screw (M3x8) 2 pcs.
[8
]
[7][6]
[2] [3] [4]
