6-21
Printing Environment Settings
6
SETUP Menu Settings
OFFSET X: As the value increases, the gutter width in the X direction
increases.
As the value decreases, the gutter width in the X direction
decreases.
IMPORTANT
If any part of the print image lies outside the printable area after adjusting the
printing position, the part will be missing in the print result.
NOTE
Each time you press [ ], the value increases in 0.5 mm increments, and each
time you press [ ], the value decreases in 0.5 mm increments. If you keep
holding down [ ] or [ ], the speed of the value changing is increased.
BIND.LOCATION
LONG EDGE*, SHORT EDGE
Specifies which edge of the paper, the long edge or short edge, is to be bound.
When you want to bind paper on which 2-sided printing is performed, the printer
adjusts the binding location automatically according to the paper surface.
Specify the binding location (top/bottom/left/right) and its width in GUTTER (See
the next item).
If LONG EDGE is specified, the binding location is created on the long edge of the
paper.
Y
X
DEFABC
ABC
Range adjusted by "OFFSET X"
Front Back Front
+ direction
Back
Y
X
DEF
Range adjusted
by "OFFSET Y"
Adjust using
OFFSET X
and OFFSET Y
+ direction
Original margin
Gutter
Front Back
Gutter
Front Back
2-sided printing in
portrait orientation
2-sided printing in
landscape orientation
DEFABC
ABC
DEF
Gutter
Gutter
To Next Page
