Product Specifications
5
Machine model, type
S100
One-way dump
Swivel dump
Electrical equipment
Battery type
75D23R
Battery capacity
V/AH
12 / 52
Working lamp
[V/W]
[12 / 18.4]
Travel Performance
Travel speed
km/h
0.0 ~ 5.4
Minimum turning radius
m
1.55
Gradeability
deg
25 (unloaded)
HST fluid capacity
liters
20
Power train
Main gearshifting method
Twin HST
Steering system
Twin HST two levers
Brake system
Internal expanding type brake
Crawler
230 × 48 × 72
Dump system
Dump system
Front dump
Swivel dump
Hydraulic pump
Type
Gear pump
Maximum rotational speed
rpm
2700
Maximum discharge
ℓ/min
11.0
Relief setting pressure
MPa(kg/cm
2
)
14.7 (150)
Cylinder (bore × stroke)
mm
60 × 400
Performance
Maximum lifting angle
deg
90
Lifting time
sec
About 6.0
About 6.3
Lowering time
sec
About 4.0
About 5.1
Hydraulic fluid capacity
liters
1.6
Combination with HST
fluid
Rotating
device
Rotating system
—
Hydraulic pressure
(twin cylinder)
Maximum rotating angle
deg
—
Right: 90 ~ Left: 90
Rotating time
sec
—
About 3.0 (90°)
Cylinder (bore × stroke)
mm
—
50 × 160
* These specifications are subject to change without notice, for product improvement.
5.2 Details of Tool Bag
No.
Part name
Quantity
Remarks
1
Operation and maintenance manual (This manual)
1
2
Instruction manual for engine
1
3
Grease fitting
1
M6
