7
Maintenance
7.8 Adjustments
7.8.1 Bleeding Air from Fuel System
To avoid engine starting malfunction, bleed air from fuel system after fuel filter
or
fuel pipe replacements, or after any operation when fuel tank was completely
emp-
tied.
1. Fill the fuel tank with fuel.
2. Turn the starting switch to the [ (ON)] position to
ON
start the fuel pump for about 5 seconds (automatic
air bleeding system).
7.8.2 Parking Brake
● Proper brake performance is critical for safety. Always keep brake adjusted
for
maximum
performance.
● Use the brake with the steering lever in the neutral
position.
Safety cover
Turnbuckle
Spring
1. Remove the safety cover.
2. Surely lock the parking brake pedal.
3. Loosen the lock nut, and adjust the spring hook inner
dimension to 67 to 68 mm by turning the turnbuckle.
4. After adjustment, tighten the lock nut firmly.
Lock nut
To Next Page
