6
Operation
3. Push the throttle lever to the [ (LOW SPEED)] to
lower the speed of the engine.
Parking brake lock
lever
Parking brake pedal
4. With the parking brake pedal depressed, pull out the
parking brake lock lever to lock the brake.
5. Turn the key in the ignition switch to the
[ (OFF)] position, then remove the key.
6. Open the engine cover, and lock it with the stay-bar.
(See page 15)
7. Turn the fuel cock to the [OFF] position.
Fuel cock
3667M-0604-050
To Next Page
