-23-
Operation 4
3683M-0402-100E
Engine Cover Stay
3. Pull the lower end of engine cover stay to
undo it. Close engine cover.
4. Start the engine by following the steps 1-10
of the normal starting procedure.
3683M-0402-110E
Off On
5. When the engine is fully warmed up, stop
the engine by turning main switch to [ (off)]
position.
3683M-0402-120E
Clutch Lever
6. Open the engine cover and raise clutch lever
to engage the clutch.
7. Close engine cover.
8. Start engine normally.
To Next Page
