-53-
Maintenance 5
Greasing
• Follow the maintenance schedule to grease the machine. Lack of greasing may
result in rust, excessive wear or seizure.
1
2
3
4
5
6
7
8
3683M-0507-120E
Greasing
Points
5
4
7
6
321
8
1. Grease greasing points as shown below.
• Grease to use: Chassis Grease
• When using a manual grease gun, pump 5-6 times. When the handle of the gun
becomes heavy, stop pumping immediately.
• When using a pneumatic grease gun, pump it for a few seconds.
NOTE
To Next Page
