CanyCom S160 - Fuses

Maintenance
-56-
5
Fuses
1. Open engine cover.
2. Open the lid of fuse housing.
• If a fuse blows, investigate the cause before replacing. Always replace a fuse
with the one of the correct rating.
• Rapid charging is only an emergency measure. This method uses a large amount of
current to compensate the lost charge in a short time. However, the battery needs
to be fully charged in the ordinary method for a longer service life.
NOTE
3683M-0508-030E
Fuse Housing
1. Remove battery from the machine.
2. Remove all ller plugs.
3. Follow the instructions in the battery
charger user's manual to charge the
battery.
4. When battery is fully charged, put ller plugs
back in place and install battery.
Charging
UPPER LEVEL
LOWER LEVEL
‑
+
+ ‑
3570M-0509-030E
3683M-0508-040E
Fuses
3. Locate the blown fuse and replace it with a
new one of the correct rating.
4. Put the lid back in place.
5. Close engine cover.
• Replacement Fuse: 40A (2pcs.)
NOTE
