Maintenance
-44-
5
1. Open engine cover.
2. When the engine is cold, check engine
coolant level in reservoir tank. If the level is
below [FULL] mark, add water.
3. Open radiator cap.
4. Check engine coolant level. If the level is
low, add water.
5. Put radiator cap back in place.
6. Close engine cover.
3683M-0506-060E
Radiator Cap
Coolant Reservoir
Inspecting/Filling
• When coolant temperature warning lamp
is lit, it may mean the coolant level is low.
Immediately inspect and add water as
necessary.
NOTE
When this machine is shipped from the factory,
it is filled with a mixture of 40% antifreeze and
60% water. To prevent coolant from freezing, use
a mixture of water and antifreeze determined by
the minimum temperature in the operation area
using the table on the left.
Antifreeze Mixture (Reference)
Ambient
Temperature
Antifreeze
Mixture
-10 °C
30%
-15 °C
35%
-20 °C
40%
-25 °C
45%
* The value for the ambient temperature
is 5°C lower than the actual minimum
temperature.
• Antifreeze to use: Long Life Coolant (LLC).
• Use pure water to make antifreeze mixture.
NOTE
