Transporting
-64-
7
3683M-0701-010US
More than 4 times
the height
Height
Loading to the Transporter
1. Park the transporter. Secure the wheels with chocks.
2. Place the loading ramps. Secure the hooks of the ramps firmly and flush with the
loading deck.
3. Drive the machine slowly backward onto the loading deck.
4. Park the machine according to the instructions in "Parking" (Page 28).
5. Tie the machine at lift hooks with rope or tie-
down belts and secure it onto the loading
deck of the transporter securely.
Unloading from the Transporter
1. Park the transporter. Secure the wheels with chocks.
2. Undo rope or tie-downs that secure the machine.
3. Place the loading ramps. Secure the hooks of the amps rmly and ush with the loading
deck.
4. Drive the machine slowly forward from the loading deck to the ground.
3683M-0701-020US
Lift Hooks
