8555-M210-O1 Rev R 758C Owner’s 20
IMPORTANT! Once the Gravity Constant has been set, both CALgC
and oPgC= must be set to the same value to disable it.
SETUP AND CALIBRATION, CONT.
CALgC (CALIBRATED GRAVITY CONSTANT)
With display showing CALgC, press PRINT/ENTER key to show current setting. This is the
acceleration of gravity value of the location where the scale was calibrated.
If the value displayed is acceptable, press PRINT/ENTER key to save it. Otherwise, using
numeric keys, enter a new value and then press PRINT/ENTER key to save it. Consult the
factory Tech Support for the Acceleration of Gravity value for your location.
OPgC= (OPERATING GRAVITY CONSTANT)
With display showing OPgC=, press PRINT/ENTER key to show current setting. This is the
acceleration of gravity value for the location where the scale will be operated.
If setting displayed is acceptable, press PRINT/ENTER key to save it. Otherwise, using
numeric keys, enter a new value and then press PRINT/ENTER key to save it. Consult the
factory Tech Support for the Acceleration of Gravity value for your location.
int= (INTERVAL SETTING)
Press PRINT/ENTER key to show current setting. If value displayed is acceptable, press
PRINT/ENTER key to save it. Otherwise, using numeric keys, enter a new value and then
press PRINT/ENTER key to save it. Allowable values are 1, 2, 5 or 10.
NOTE: If you select an interval value of 10 (int=10), dPP= prompt will not be shown.
Setup will proceed to CAP=, scale capacity setting prompt.
Unit= (WEIGHING UNIT)
With display showing Unit=, press PRINT/ENTER key to show current setting. If value
displayed is acceptable, press PRINT/ENTER key again to save it. Otherwise, using numeric
keys, enter a new value and then press PRINT/ENTER key to save it. Allowable values are:
0 = None 3 = Pounds/Kilograms 6 = Grams Only
1 = Pounds Only 4 = Kilograms/Pounds 7 = Stones and Pounds
or Kilograms
2 = Kilograms Only 5 = Ounces Only
IMPORTANT! If Unit=7 (7 = Stones and Pounds or Kilograms) is selected, the value
selected for int= (Scale Interval) and dPP= (Decimal Point Position) must be set to (1).
NOTE: Weight display for Stones and Pounds/Kilograms mode is XX.YY.Y,
where XX is weight in Stones and YY.Y is remainder of the weight in pounds.
Please note that in this mode, "ST" and "lb" annunciators will be turned on.
dPP= (DECIMAL POINT POSITION)
With display showing dPP=, press PRINT/ENTER key to show current setting. If value
displayed is acceptable, press PRINT/ENTER key to save it. Otherwise, using numeric keys,
enter a new value and then press PRINT/ENTER key to save it. Allowable values are:
0 = XXXXXX 1= XXXXX.X 2 = XXXX.XX 3 = XXX.XXX
