8555-M210-O1 Rev R 758C Owner’s 40
PARTS IDENTIFICATION, CONT.
Inside Rear View Detail
ITEM QTY. PART NUMBER DESCRIPTION
2 4 6013-0039 NUT HEX #6-32
7 2 6024-0126 WASHER FLAT FOR 5/32” POP RIVET
9 1 6610-5119 BATTERY HOLDER 6-C CELLS
12 8 6680-0004 WASHER LOCK INT. TOOTH #6 Z/P
14 4 6680-0138 SPACER #6 X .187 NYLON
15 2 6680-0214 POP RIVET BH AL 5/32 DIA
16 1 8200-B369-08 GROUND SPRING
21 1 8555-B461-0A CABLE: BATTERY
24 1 8555-C450-0A FRONT PANEL WELDMENT
26 1 8555-D444-0A BOARD ASSEMBLY – 758C
