Carel srl: pCO Stage Controller
page 6
Printer button
Code Description Default Rating Units of
measure
Pr1
immediate printing request (only if P42=1) 0
0→disable 1→enable
Pr2
selection of the cyclic printing time (only if P42=1) 60 0÷999 min
I/O button
Code Description Default Rating Units of
measure
Ai1 display of the value detected by the probe 1 -99÷99.9 °C/F°/bar
Ai2 display of the value detected by the probe 2 -99÷99.9 °C/F°/bar
Ai3
selection with a potentiometer of the probe 1 setpoint (only if P21=1) or
display of the ambient air temperature (only if P21=0 and if P22=1)
-99÷99.9 °C/°F/bar
Ai4 display of the remote on/off state 0
→
off;
1
→
on
i1 state of the device 1 lock alarm 0
→
off;
1
→
on
i2 state of the device 2 lock alarm 0
→
off;
1
→
on
i3 state of the device 3 lock alarm 0
→
off;
1
→
on
i4 state of the device 4 lock alarm 0
→
off;
1
→
on
i5 state of the device 5 lock alarm 0
→
off;
1
→
on
i6 state of the device 6 lock alarm 0
→
off;
1
→
on
i7 state of the device 7 lock alarm 0
→
off;
1
→
on
i8 state of the device 8 lock alarm 0
→
off;
1
→
on
i9 state of the device 9 lock alarm 0
→
off;
1
→
on
i10 state of the device 10 lock alarm 0
→
off;
1
→
on
i11
state of the device 11 or fan-inverter lock alarm 0
→
off;
1
→
on
i12 state of the low pressure/flow regulator alarm 0
→
off;
1
→
on
Ao1 display of the state of the fan inverter
0÷10.0
volt
Ao2 display of the state of the device 1/valve
0÷10.0
volt
o1 state of the device 1 0
→
off;
1
→
on
o2 state of the device 2 0
→
off;
1
→
on
o3 state of the device 3 0
→
off;
1
→
on
o4 state of the device 4 0
→
off;
1
→
on
o5 state of the device 5 0
→
off;
1
→
on
o6 state of the device 6 0
→
off;
1
→
on
o7 state of the device 7 0
→
off;
1
→
on
o8 state of the device 8 0
→
off;
1
→
on
o9 state of the device 9 0
→
off;
1
→
on
o10 state of the device 10 0
→
off;
1
→
on
Clock button
Code Description Default Rating Unit of
measure
C1 hour display (only if P41=1) 0÷23 h
C2 minute display (only if P41=1) 0÷59 min
C3 day display (only if P41=1) 1÷31
C4 month display (only if P41=1) 1÷12
C5 year display (only if P41=1) 0÷99
PSC
password that allows the access to the subsequent param. (only
if P41=1)
0 0÷999
C6 hour selection (only if P41=1) 0 0÷23 h
C7 minute selection (only if P41=1) 0 0÷59 min
C8 day selection (only if P41=1) 0 1÷31
C9 month selection (only if P41=1) 0 0÷99
C10 year selection (only if P41=1) 0 0÷99
C11
range-beginning hour with secondary set (only if P41=1) 0 0÷23 h
