2 DESCRIPTION OF THE MACHINE
2.1 GENERAL DESCRIPTION OF THE MACHINE
The following image is only an example and may di󰀨er in colour from the ma-
chine purchased.
The machine can be set up (modular) according to cu󰀬omer’s requirements.
The main components are li󰀬ed below. Any conguration might be equipped
with more or fewer options according to the cu󰀬omer’s needs.
09
Display
Steam tap
Steam wand
Small
cup shelf
Drip tray
Power switch
Cup warmer
Dispensing
push-button panel
Co󰀨ee group
Pressure gauge
Hot water spout
Stainless
󰀬eel grid
Water
connection
Water drain and
boiler emptying
Dosed hot
water button
