Motor Controllers AC Variable Frequency Drives Type VariFlex
3
RVLF
232 Specications are subject to change without notice. Pictures are just an example. For special features and/or customization, please ask to our sales network. 13/12/2017
Command DATA (Readable and Writable)
Register Content
2501H
Operation signal
2502H Frequency Command
2503H ~ 251FH (unused)
Bit Meaning 1 0
0 Operation Command Run Stop
1 Reverse Command Reverse Forward
2 External Fault Fault (EFO)
3 Fault Reset Reset
4 Jog Command Jog
5 Jog Reverse Command Jog reverse
6 Multi function Command S1 ON OFF
7 Multi function Command S2 ON OFF
8 Multi function Command S3 ON OFF
9 Multi function Command S4 ON OFF
A Multi function Command S5 ON OFF
B (unused)
C Relay R1 ON OFF
D (unused)
E~F (unused)
Note: The unused Bit is dened as 0, the spare register is not available for writing data.
