LEGEND LRA – Locked Rotor Amps MCC – Maximum Continuous Current RLA – Rated Load Amps * The last two digits of the compressor model number may vary. See page 3. NOTES: 1. RLA (rated load amps) value shown for new high efficiency models is MCC ÷ 1.56 - RLA. Use this recommended (and minimum) RLA value to determine nameplate stamping, mini- mum contactor sizing and wire sizing. 2. Compressor operating amps at any specific conditions can only be determined from a performance curve. 3. RLA values for 06D compressor protected by a calibrated circuit breaker will depend on must-trip value of circuit breaker. 4. Ohm values shown for resistance are approximate and shown for reference only. Motors from different vendors and motors of different efficiencies can differ up to 15% from data shown.
NEW HIGH EFFICIENCY MODELS OLD STANDARD EFFICIENCY MODELS
Compressor
Model*
Electrical Data
HP
Compressor
Model*
Electrical Data
Volt MCC RLA LRA
Motor
Winding
Resistance
(Ohms)
MAX
(kW)
Volt MCC RLA LRA
06DA (continued)
06DA8242BA3150
BA3250 BA3650
575
208/230
460
22.2 55.5 27.8
14.2 35.6 17.8
79
198
99
2.0
0.31
1.3
12.8 7.5
06DA8242BA0100
BA1200 BA0600
575
208/230
460
22.2 61.5 27.8
15.9 43.9 19.9
62
170
77
06DA8252BA3150
BA325
0
BA3650
575
208/230
460
22.2 55.5 27.8
14.2 35.6 17.8
79
198
99
2.0
0.31
1.3
12.8 7.5 N/A N/A N/A N/A N/A
06DA3282BA3150
BA3250 BA3650
575-3-60
208/230
460
25 62 31
16.0 39.7 19.9
91
228 114
1.7
0.26
1.0
16.5 10
06DA3282BA0100
BA1200 BA0600
575
208/230
460
25 69 31
17.9 49.3 22.1
69
191
86
06DA5372BA0150
BA1250 BA0650
575
208/230
46
0
32 89 40
20.5 57.1 25.6
96
266 120
1.2
0.18 0.72
20.7 15
06DA5372BA0100
BA1200 BA0600
575
208/230
460
32 89 40
22.9 63.6 28.6
96
266 120
ALLOWABLE OPERATING RANGES
NOMINAL
VOLTAGE
MAXIMUM MINIMUM
208/230
460 575
400 (50 Hz) 200 (50 Hz)
254 529 661 460 230
187 414 518 342 180
