Carlyle 06D - Exploded View - 6-Cylinder 06 E Compressor

58
Complete parts break- down shown for refer- ence only. Some parts may be pictured prior to design changes and not all parts are avail- able as replacements.
2.9 — Exploded View - 6-Cylinder 06E Compressor
LEGEND
1—Compressor Motor - Stator
and Rotor
2—Motor Key 3—Rotor Plate Washer 4—Rotor Lock Washer 5—Rotor Lock Bolt 6—Motor Lock Bushing 7—Roll Pin 8—Acorn Nut and Gasket
