4.6 — 06EA, ET 3 Phase Electrical Specifications
LEGEND
LRA – Locked Rotor Amps
MH – Must Hold Amps
MT – Must Trip Amps
PW – Part Winding (Start)
RLA – Rated Load Amps
XL – Across-the-Line (Start)
* The last two digits of the compressor model number may vary. See page 4. The fifth digit in () of the compressor model number represents models
with or without oil. 0, 1, 2 signifies older models with oil; 3, 4, 5 signifies newer models without oil. See page 4.
† Refer to revised Bulletin 03T-2 for recommended motor protection.
COMPRESSOR MOTOR DATA CIRCUIT BREAKER DATA†
COMPRESSOR
MODEL*
VOLT
MAX
kW
HP
SEE NOTE 1 SEE NOTE 2
MOTOR
WINDING
RESISTANCE
(Ohms)
SEE NOTE 3
M.H. M.T. LRA
SEE NOTE
4
Maximum
Must Trip
Amps
Maximum
RLA
LRA-XL
LRA-PW
(first
winding)
Recommended
Circuit Breaker
Part No.
RLA with
Listed
Breaker
06EA(2/5)50000
(2/5)50100
(2/5)50600
(2/5)50300
208/230
575
460
208/230/460
25.3 20
108
45
54
108/54
87
36
44
87/44
345
120
173
345/173
207
72
104
207/104
0.32
2.2
1.3
0.32/0.16
HH83XB625
XB422
XB606
XB625/XB606
91
33
42
91/42
104
38
49
104/49
350
124
175
350
/175
74.3
27.1
35
74.3/35
06EA(2/5)65000
(2/5)65100
(2/5)65600
(2/5)65300
208/230
575
460
208/230/460
33.6 25
140
57
70
140/70
112
46
56
112/56
446
164
223
446/223
268
98
134
268/134
0.27
1.6
1.1
0.27/0.14
HH83XC509
XB615
XB607
XC509/XB607
110
46
55
110/55
127
53
64
127/64
420
164
210
420/210
90.7
37.9
45.7
90.7/45.7
06EA(2/5)75000
(2/5)75100
(2/5)75600
(2/5)75300
208/230
575
460
208/230/460
39.1 30
168
65
84
168/84
135
52
68
135/68
50
6
176
253
506/253
304
106
152
304/152
0.22
1.3
0.9
0.22/0.11
HH83XC539
XB683
XB609
XC539/XB609
142
50
63
142/67
163
58
76
163/76
507
168
274
507/274
116.4
41.4
54.3
116.4/54.3
06EA(2/5)99000
(2/5)99100
(2/5)99600
(2/5)99300
208/230
575
460
208/230/460
54.0 40
236
94
118
236/11
8
189
75
95
189/95
69
0
276
345
690/345
414
165
207
414/207
0.15
1
0.58
0.15/0.07
HH83XC537
XB636
XB405
XC537/XB405
187
74
92
187/92
215
85
106
215/
106
636
236
295
636/295
153.6
60.7
75.7
153.6/75.7
