3.15 — Capacity Control Accessory Packages (Suction
Cut-Off Unloading Type)
The following suction cut-off capacity control packages are
available to field convert those 06D, 06E compressors with-
out unloading. With the exception of the 06D 2-cylinder
models, these packages can be added to any new, replace-
ment, or existing 06D or 06E compressors. See Fig.22.
NOTE: Before adding a suction cut-off control package to
a
compressor currently without unloading, consider all line
piping sizes and design to ensure proper oil return to com-
pressor with reduced (unloaded) refrigerant flow rates.
CYLINDER HEAD COOLING FAN REPLACEMENT PARTS
DESCRIPTION 06D, 06CC (16 to 37 Cfm)
06E, 06CC (50 to 99
Cfm)
Head cooling fan assembly
- 208/230V
06DA680070 06DA680072
Head cooling fan assembly
- 460V
06DA680071 06DA680073
Head cooling fan assembly,
less mounting - 208/230V
06DA680074 06DA680074
Head cooling fan assembly,
less mounting - 460V
06DA680075 06DA680075
Mounting kit 06DA680076 06DA680077
Replacement motor - 208/
230V
06DA680079 06DA680079
Replacement motor - 460V 06DA680078 06DA680078
Replacement fan blade 06DA680080 06DA680080
Mounting stud nuts 3/8 - 16 1/2 - 13
