SERVICE RETROFIT KITS (SINGLE PHASE):
The below kits are intended to service Carlyle 06D and
06CC (16-37 Cfm) compressors manufactured BEFORE
August 2015, S/N starting with '3115', with the factory
installed electromechanical overcurrent protection and a sin-
gle phase motor. The provided service kits are for RETRO-
FIT of an existing compressor with the electromechanical
overcurrent protection to the electronic overcurrent protec-
tion scheme. When selecting the appropriate kit, please be
sure to select the required control voltage, as the retrofit
module will require OEM customers to provide control volt-
age to the terminal box of the compressor. All kits include
a
replacement large folded terminal box, electronic overcur-
rent protection module and current transformer, with a pre-
programmed MCC value based on the compressor model
number. For additional information on the kit and installa-
tion, please see 99TA516185A located on the Carlyle Com-
pressor website (www.carlylecompressor.com).
COMPRESSOR
MODEL NUMBER
ELECTRONIC OVERCURRENT PROTECTION
SERVICE RETROFIT (SINGLE PHASE) KIT NUMBER
MCC
Control Voltage
110-220V 24V AC 24V DC (Amps)
06D * 013 * * A33 * * 06DA6706DBSB0326 06DA6706DBSC0326 06DA6706DBSD0326 32.6
06D * 109 * * A03 * * 06DA6706DBSB0240 06DA6706DBSC0240 06DA6706DBSD0240 24.0
06D * 109 * * A33 * * 06DA6706DBSB0240 06DA6706DBSC0240 06DA6706DBSD0240 24.0
06D * 313 * * A03 * * 06DA6706DBSB0568 06DA6706DBSC0568 06DA6706DBSD0568 56.8
06D * 313 * * A33 * * 06DA6706DBSB0400 06DA6706DBSC0400 06DA6706DBSD0400 40.0
06D * 316 * * A03 * * 06DA6706DBSB0568 06DA6706DBSC0568 06DA6706DBSD0568 56.8
06D * 316 * * A33 * * 06DA6706DBSB0400 06DA6706DBSC0400 06DA6706DBSD0400 40.0
06D * 518 * * A03 * * 06DA6706DBSB0568 06DA6706DBSC0568 06DA6706DBSD0568 56.8
06D * 718 * * A33 * * 06DA6706DBSB0400 06DA6706DBSC0400 06DA6706DBSD0400 40.0
06D * 808 * * A03 * * 06DA6706DBSB0280 06DA6706DBSC0280 06DA6706DBSD028028.0
06D * 808 * * A33 * * 06DA6706DBSB0280 06DA6706DBSC0280 06DA6706DBSD028028.0
