06CC COMPRESSORS
06CC 6 65 E 201
Design Variable:
101 = Single Pack, W/O Valves, with Oil
102 = Single Pack with Valves & Oil
103 = Single Pack, Service W/O Valves and Term. Box or Oil
201 = Single Pack, W/O Valves or Oil
202 = Single Pack with Valves
Electrical Characteristics:
A = 415-3-50, XL and PW
B = 415-3-50, XL
C = 415-3-50, PW
D = 208/230-3-60, XL
E = 208/230/400/460-3-50/60
F = 400/460-3-50/60, XL and PW
G = 400/460-3-50/60, XL
H = 400/460-3-50/60, PW
J = 575-3-60, XL and PW
K = 230-3-60, PW
L = 220-3-50, XL and PW
M = 220-3-50, XL
N = 220-3-50, PW
P = 220/346/380-3-50/60, XL and PW
Displacement (in Cfm at 1750 rpm) (See Note below)
Motor Size and Protection:
0 = 15 FT-LB / 5 HP
A = 15 FT-LB / 5 HP
B = 15 FT-LB / 5 HP
C = 15 FT-LB / 5 HP
1 = 20 FT-LB / 6.5 HP
D = 20 FT-LB / 6.5 HP
E = 20 FT-LB / 6.5 HP
F = 20 FT-LB / 6.5 HP
2 = 24 FT-LB / 7.5 HP
G = 24 FT-LB / 7.5 HP
H = 24 FT-LB / 7.5 HP
J = 24 FT-LB / 7.5 HP
3 = 24 FT-LB / 7.5 HP
K = 24 FT-LB / 7.5 HP
L = 24 FT-LB / 7.5 HP
M = 24 FT-LB / 7.5 HP
5 = 45 FT-LB / 15 HP
6 = 60 FT-LB / 20 HP
7 = 75 FT-LB / 25 HP
8 = 90 FT-LB / 30 HP
Compressor Type:
06CC = Compound Cooling Model
06CY = Service Compressor
06C8 = Compressor, Special
NOTE: USE OF “Cfm” AS MODEL SIZE DESIGNATION
Carlyle uses the “Cfm” designation in the model number to identify the compressor size. The Cfm values are the sixth and
seventh digits of the model number. See example above. Carlyle offers two series of compressors based on body size.
The smaller compressors, from 8 to 37 Cfm, are referred to as “D” size units (model number “06D”). The larger
compressors, from 50 to 99 Cfm, are referred to as “E” size units (model number “06E”).
The 06CC, or Compound Cooling compressors, are made in 16 to 37 Cfm and 50 to 99 Cfm sizes.
The 16 to 37 Cfm compressors use “D” size bodies. The 50 to 99 Cfm compressors use “E” size bodies.
NOTE: METRIC MEASUREMENTS
The compressors are built using English units: inches, foot-pounds, pints, etc. A corresponding metric measurement
has been added to all the English units in this guide. These metric measures are a guide only, having been rounded
to the nearest whole number, and therefore are not meant to be an exact mathematical conversion.
S = Oil Sensor Block and OPSS sensor (shown as the 10th digit)
Information in shaded area is no longer available in standard factory production.
5th Digit
Motor Size
Overload Variable
Electromechanical Overcurrent Protection (*No Longer Available)
115/240V Control Voltage, Electronic Overcurrent Protection
24V AC Control Voltage, Electronic Overcurrent Protection
24V DC Control Voltage, Electronic Overcurrent Protection
Electromechanical Overcurrent Protection (*No Longer Available)
115/240V Control Voltage, Electronic Overcurrent Protection
24V AC Control Voltage, Electronic Overcurrent Protection
24V DC Control Voltage, Electronic Overcurrent Protection
Electromechanical Overcurrent Protection (*No Longer Available)
115/240V Control Voltage, Electronic Overcurrent Protection
24V AC Control Voltage, Electronic Overcurrent Protection
24V DC Control Voltage, Electronic Overcurrent Protection
Electromechanical Overcurrent Protection (*No Longer Available)
115/240V Control Voltage, Electronic Overcurrent Protection
24V AC Control Voltage, Electronic Overcurrent Protection
24V DC Control Voltage, Electronic Overcurrent Protection
Not Factory Installed, External Overcurrent Protection Required
Not Factory Installed, External Overcurrent Protection Required
Not Factory Installed, External Overcurrent Protection Required
Not Factory Installed, External Overcurrent Protection Required
Q = 380-3-60, XL
