REMOVAL PROCEDURE OF OUTDOOR UNIT -- 42K

Steps Procedure

1. Disassemble the cover plate

2. Disassemble the front panel

3. Disassemble the panel on the right side

① Remove the fixed screws on the cover plate by

using a screwdriver.

② Remove the cover plate.

① Remove the fixed screws on the front panel by

using a screwdriver.

② Remove the front panel.

① Remove the fixed screws on the panel by using

a screwdriver.

② Remove the panel on the right side.
