Carrier 40GVM Series - Page 65

65
Steps Procedure
4. Dismount the grille
5. Disassemble the outer casing
6. Disassemble the fan blades
① Remove the fixed screws on the grille by using
a screwdriver.
② Remove the grille.
① Remove the fixed screws on the outer casing by
using a screwdriver.
② Remove the outer casing.
① Remove the fixed screws on the fan blades by
using a spanner.
② Remove the fan blades.
