58TP0B/58TP1B: Installation, Start-up, Operating and Service and Maintenance Instructions
Manufacturer reserves the right to change, at any time, specifications and designs without notice and without obligations.
27
070V17--16
1 Cont. Fan 565 480 395 325 260 180 - - - -
2 620 545 470 395 330 265 195 140 - -
3 695 630 560 495 425 360 305 245 175 -
4 765 700 640 575 515 455 395 345 285 225
5 825 770 710 650 595 535 480 420 375 325
6 885 830 775 720 665 610 555 505 450 405
7 960 910 860 810 755 705 655 600 550 500
8 1030 980 935 885 835 785 740 690 645 595
9 1095 1050 1005 960 915 865 820 775 730 685
10 Low Heating 1130 1080 1035 995 950 905 860 815 770 725
11 1175 1130 1085 1045 1000 960 915 870 830 785
12 High Heating 1245 1200 1160 1120 1080 1040 1000 955 915 875
13 1270 1230 1190 1150 1110 1070 1030 990 950 910
14 1315 1275 1235 1195 1155 1120 1080 1040 1000 960
15 Low Cooling 1355 1315 1275 1240 1200 1165 1125 1090 1050 1010
16 1395 1355 1315 1280 1240 1205 1170 1135 1095 1060
17 1470 1430 1395 1360 1325 1285 1255 1220 1185 1150
18 1510 1475 1440 1405 1370 1335 1300 1265 1235 1200
19 1550 1515 1480 1445 1410 1375 1345 1310 1280 1245
20 1590 1555 1520 1490 1455 1420 1385 1355 1325 1290
21 1630 1595 1560 1530 1495 1460 1430 1395 1365 1335
22 1665 1630 1600 1565 1535 1500 1470 1440 1410 1380
23 1720 1685 1655 1620 1590 1560 1525 1495 1465 1435
24 1775 1745 1710 1680 1650 1620 1585 1555 1525 1480
25 High Cooling 1845 1810 1780 1750 1715 1665 1620 1570 1525 1480
090V17--16
1 Cont. Fan 660 580 480 410 340 265 210 150 - -
2 700 625 525 455 395 320 255 205 145 -
3 750 685 585 520 460 395 325 270 220 165
4 805 740 670 580 520 465 405 335 280 235
5 855 795 730 640 580 520 465 405 345 295
6 900 845 785 695 635 580 525 470 410 355
7 945 890 835 770 685 630 575 530 475 415
8 975 925 865 810 725 665 615 565 515 460
9 1015 965 915 860 775 715 665 615 570 520
10 Low Heating 1070 1020 970 920 865 785 730 680 630 590
11 1130 1085 1040 990 945 865 805 755 710 665
12 1170 1125 1080 1030 985 930 855 805 760 710
13 Low Cooling 1200 1155 1115 1070 1020 975 900 845 800 755
14 Hiigh Heating 1240 1200 1160 1115 1070 1025 980 905 855 810
15 1260 1220 1180 1140 1095 1050 1005 935 880 840
16 1295 1255 1215 1175 1130 1090 1045 980 925 880
17 1325 1285 1250 1210 1170 1125 1085 1035 965 920
18 1360 1325 1285 1245 1210 1165 1125 1085 1015 960
19 1395 1360 1320 1285 1245 1205 1165 1125 1075 1010
20 1430 1390 1355 1320 1285 1245 1205 1165 1125 1060
21 1460 1425 1390 1355 1320 1280 1245 1205 1165 1115
22 1500 1465 1430 1395 1360 1320 1285 1245 1210 1170
23 1535 1500 1465 1430 1400 1360 1325 1290 1255 1215
24 1575 1540 1505 1475 1440 1405 1370 1335 1285 1225
25 High Cooling 1615 1580 1545 1515 1480 1450 1410 1350 1285 1225
Table 10 – Air Delivery - CFM (with Filter)* (Continued)
Unit Size
Airflow
Setting
Default Setting
External Static Pressure (in.w.c.)
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1
