58TP0B/58TP1B: Installation, Start-up, Operating and Service and Maintenance Instructions
Manufacturer reserves the right to change, at any time, specifications and designs without notice and without obligations.
28
090V21--20
1 Cont. Fan 780 660 545 440 330 210 - - - -
2 860 740 645 535 440 340 220 - - -
3 930 820 725 625 530 440 350 230 - -
4 1030 930 835 755 655 570 485 400 310 185
5 1125 1035 935 860 785 690 610 530 450 370
6 1210 1125 1035 955 880 805 725 645 570 495
7 1285 1210 1125 1040 975 905 830 750 675 610
8 1385 1310 1235 1150 1085 1020 955 885 815 745
9 1475 1410 1340 1265 1190 1130 1065 1010 940 875
10 Low Heating 1565 1500 1435 1365 1290 1230 1175 1115 1060 995
11 1670 1605 1550 1485 1415 1350 1295 1240 1180 1130
12 High Heating/Low Cooling 1720 1660 1605 1540 1475 1410 1350 1300 1245 1195
13 1765 1710 1655 1595 1530 1465 1405 1355 1305 1255
14 1815 1760 1705 1650 1585 1525 1460 1410 1360 1310
15 1860 1805 1755 1700 1640 1580 1515 1465 1415 1370
16 1915 1865 1815 1760 1705 1645 1585 1530 1480 1435
17 1970 1915 1865 1815 1760 1705 1645 1590 1540 1495
18 2020 1965 1920 1870 1820 1765 1710 1650 1605 1560
19 2070 2025 1975 1930 1880 1830 1775 1720 1670 1625
20 2120 2075 2030 1985 1935 1885 1835 1785 1730 1685
21 2170 2125 2080 2035 1990 1945 1895 1845 1795 1750
22 2220 2175 2130 2090 2045 2000 1955 1910 1860 1815
23 High Cooling 2270 2225 2185 2145 2100 2055 2015 1970 1920 1875
24 2355 2315 2275 2240 2200 2160 2115 2075 2020 1965
25 2470 2425 2385 2335 2285 2230 2175 2115 2050 1985
110V21--22
1 Cont. Fan 815 690 580 475 375 285 190 - - -
2 890 780 670 570 475 385 300 215 135 -
3 1000 900 800 700 615 525 440 360 285 210
4 1100 1005 910 820 735 650 570 490 415 350
5 1190 1105 1015 930 840 765 685 610 535 465
6 1280 1195 1110 1025 945 865 795 725 645 575
7 1385 1305 1225 1150 1070 995 920 860 790 720
8 1480 1405 1335 1260 1190 1120 1045 975 920 850
9 1575 1505 1435 1365 1295 1230 1165 1095 1030 975
10 Low Heating 1685 1620 1555 1485 1420 1360 1295 1230 1165 1105
11 Low Cooling 1785 1725 1660 1600 1535 1475 1415 1355 1300 1235
12 1880 1825 1765 1705 1645 1590 1530 1470 1415 1365
13 High Heating 1935 1880 1825 1765 1710 1650 1595 1545 1490 1435
14 1995 1940 1885 1825 1770 1715 1660 1605 1555 1505
15 2010 1960 1905 1850 1790 1740 1685 1630 1580 1530
16 2060 2005 1950 1900 1840 1790 1735 1685 1635 1585
17 2095 2045 1990 1940 1885 1835 1780 1730 1680 1635
18 2140 2090 2040 1990 1935 1885 1835 1790 1740 1695
19 2190 2145 2095 2045 1995 1940 1895 1850 1805 1755
20 2250 2205 2155 2105 2055 2010 1960 1915 1870 1830
21 High Cooling 2305 2260 2215 2165 2120 2075 2030 1985 1940 1900
22 2355 2305 2260 2220 2175 2130 2085 2040 2000 1960
23 2400 2355 2315 2270 2230 2185 2145 2100 2060 2015
24 2460 2420 2375 2335 2290 2250 2205 2150 2100 2045
25 2515 2470 2430 2385 2345 2290 2230 2170 2110 2050
Table 10 – Air Delivery - CFM (with Filter)* (Continued)
Unit Size
Airflow
Setting
Default Setting
External Static Pressure (in.w.c.)
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1
