Carrier SUPRA 950Mt - Unit Modes of Operation

62-11863 2-4
Figure 2.4 Evaporator (MTS 1100 Illustrated)
1. Return Air Sensor
2. Evaporator Coil
3. Defrost Termination Temperature Sensor
4. Evaporator High Temperature Switch
5. Capacitor
6. Fan and Motor Assembly
7. Check Valve Assembly
8. Liquid Line Valve Assembly
9. Hot Gas Valve
10. Electric Heater
- - - - -
1
2
3
4
5
6
7
8
9
10
