33
Menu-COMM.08: Set COM2 RS-485 Baud Rate
Function COM1 Baud Rate Setting
Display Part Meaning
CBR2. 0 1,200 bps
CBR2. 1 2,400 bps
CBR2. 2 4,800 bps
CBR2. 3
9,600 bps
CBR2. 4 19,200 bps
CBR2. 5 38,400 bps
CBR2. 6 57,600 bps
Set Range
(0 ~ 7)
CBR2. 7 115,200 bps
Menu-COMM.09: Set COM2 Out Data
Function COM2 Out Data Setting
Display Part Meaning
CWT2. 0
Displayed value is transmitted
CWT2. 1 Gross Weight is transmitted
Set Range
(0 ~ 2)
CWT2. 2 Net weight is transmitted
Menu-COMM.10: COM2 Output Format
Function COM2 Output Format
Display Part Meaning
CFM2. 0
22 byte of CAS
CFM2. 1 10 byte of CAS
Set Range
(0 ~ 2)
CFM2. 2 18 byte Format(AND, FINE)
Note 1. Refer to <Appendix 1> for the communication format
Menu-COMM.11: COM2 Communication Method
Function COM2 Communication Method (RS-485 - Output mode)
Display Part Meaning
CMD2. 0
Data is not transmitted
CMD2. 1 Transmitted only if the print key is pushed
CMD2. 2 Transmitted in both stable/unstable cases (Stream Mode)
CMD2. 3 Transmitted only if the weight is stable
CMD2. 4 Command Type 1
CMD2. 5 Command Type 3
Set Range
(0 ~ 6)
CMD2. 6 Modbus protocol
Note 1. Refer to Appendix 2, 3 for command types.
